RL-40246 | Ø112mm |Adjustable Downlight
SPECIFICATIONS
Model no. RL-40246
Dimension (mm) 112Dia x 140H
Cutout 102mmDia
Cutoff angle 30°
Tilting angle 25°
Reflector Dark light reflector
LED TYPE Citizen
Wattage 12W/ 15W/ 20W
Beam angle 18°/ 22°/ 32°
Lumen 12W: 711/ 636/ 817 lm
18°/ 22°/ 32° 15W: 1089/ 988/ 953 lm
20W: 1269/ 1164/ 1124 lm
Efficiency 12W: 59/ 53/ 68 lm/W
18°/ 22°/ 32° 15W: 72/ 65/ 63 lm/W
20W: 63/ 58/ 56 lm/W
CCT 2700K, 3000K, 3500K, 4000K
Ra. 90+
Installation
Mounting Recessed
Ceiling Thickness 10-25mm
LED Driver Remote
Dimming Non-dim/ DALI/ 0-10V/Phase Dim
Remarks:
The above figures are calculated based on the nominal lumen and wattage value.
The above figures are based on CCT 2700K
