SPECIFICATIONS

Model no. RL-40253
Dimension (mm) 137Dia x 128H
Cutout 127mmDia

Reflector Dark light reflector
LED TYPE Citizen
Wattage 20W/ 25W/ 30W

Lumen 20W: 1429 lm
25W: 1637 lm
30W: 1833 lm

Efficiency 20W: 71 lm/W
25W: 65 lm/W
30W: 61 lm/W

CCT 2700K, 3000K, 3500K, 4000K
Ra. 90+

Installation

Mounting Recessed
Ceiling Thickness 10-25mm
LED Driver Remote
Dimming Non-dim/ DALI/ 0-10V/Phase Dim

Remarks:
The above figures are calculated based on the nominal lumen and wattage value.
The above figures are based on CCT 2700K
