RL-45012 | Ø85mm | Adjustable Downlight
SPECIFICATIONS
Model no. RL-45012
Dimension (mm) 85Dia x 90H
Cutout 75mmDia
Cutoff angle 65°
Tilting angle 30°
Reflector Chrome/ White/ Black
LED TYPE Luminous
Wattage 10W
Beam angle 15°/ 25° /35°
Lumen 460/ 532/ 591 lm
15°/ 25° /35°
Efficiency 46/ 53/ 59 lm/W
15°/ 25° /35°
CCT 2700K, 3000K, 3500K, 4000K
Ra. 90+
IP 20
Installation
Mounting Recessed
Ceiling Thickness 10-25mm
LED Driver Remote
Dimming Non-dim/ DALI/ 0-10V/Phase Dim
Remarks:
The above figures are calculated based on the nominal lumen and wattage value.
The above figures are based on CCT 2700K
Numbering System e.g. RL-45012-27-28-15-nd
| Model Number | - | Colour Temperature | Wattage | Beam Angle | - | Dimming |
|---|---|---|---|---|---|---|
| RL-45012 | 27: 2700K | 10: 10W | 15 | Nd-no-dimming | ||
| RL-45013 | 30: 3000K | 25 | 0-10: 0-10V | |||
| 40: 4000K | 35 | 220: Phase dimming | ||||
| DALI: Dali Dimming |
